รายละเอียดเพิ่มเติม
|
|
Single leg |
Endless
|
2 Legs |
3 or 4 legs
|
||
|
Chain Size (mm) |
(TON) | (TON) | 0◦-45◦
(TON) |
45◦-60◦
(TON) |
0◦-45◦
(TON) |
45◦-60◦
(TON) |
|
6.3 mm. |
1.12 | 1.87 | 1.57 | 1.12 | 2.35 | 1.64 |
|
7 mm. |
1.50 | 2.50 | 2.10 | 1.50 | 3.15 | 2.19 |
|
8 mm. |
2.00 | 3.33 | 2.80 | 2.00 | 4.20 | 2.92 |
|
9 mm. |
3.00 | 5.00 | 4.20 | 3.00 | 6.30 | 4.38 |
| 10 mm. | 3.15 | 5.25 | 4.41 | 3.15 | 6.62 |
4.60 |
| 13 mm. | 5.30 | 8.83 | 7.42 | 5.30 | 11.13 |
7.74 |
| 16 mm. | 8.00 | 13.33 | 11.20 | 8.00 | 16.80 |
11.68 |
| 19 mm. | 11.20 | 18.67 | 15.68 | 11.20 | 23.52 |
16.35 |
| 22 mm. | 15.00 | 25.00 | 21.00 | 15.00 | 31.50 |
21.90 |
